Features

Ideally Suited for Most LCD and TFT Wet Processing Applications and the Filtration of High Purity Water

Suitable for Generation 7 and 8 TFT-LCD Glass Cleaning,and High End Process Filtration Applications

Wide Range of Filter Media and Retention Ratings Available,Enabling Optimization of Critical Processes

Compact Cartridge Design Offers Long On-Stream Life Reducing Equipment Down-Time and Maintenance Costs

Various Gaskets/O-rings Materials-Compatible with Many Fluids

Manufactured,Rinsed,Tested and Packaged in a Class 10000 Clean Room Environment

Specifications

Materials of Construction:

Filter Media:                                    P  High Flow Melt Blown Polypropylene

                                                 S  Highly Asymmetric PES Membrane

                                                 T  Expanded Polytetrafluoro-ethylene(ePTFE)Membrane

Surpport Layers:                                 Polypropylene

Hardware/Core:                                   Polypropylene

Gaskets/O-Rings:                                 EPDM,Viton,Silicone,Buna-N,Teflon Encapsulated Viton

Dimensions:

Outside Diameter:                                 5.16"(131mm)

lengths:                                          10"(254mm)

*Special Specifications Could Be Made to Order

Performance

Retention Ratings:                                 P  0.22,0.45,0.8,2,5,10,20 ,30 , 50,75 ,100,μm

                                                   S  0.1,0.2,0.45,0.8,1.2,5μm Absolute

                                                   T  0.1,0.2,0.45,1,3,10μm Absolute

Maximum Operating Temperature:                           168℉(75℃)

Recommended  Change Out Differential Pressure:     30 psid(2.1bar)

Applications

Rinses for LCD and TFT Wet Processing

Final Filtration For High Purity Chemicals

Filtration for High Pressure and High Water Flow Rate in Chimical and Medcine
